GENERAL SPECIFICATIONS:
SERIAL 1907
NEW APPROXIMATELY MID 1960'S
SWING OVER BED 48"
SWING OVER CROSS SLIDE & TURRET NOMINAL 31"
SWING OVER CROSS SLIDE & TURRET, ACTUAL 32"
LENGTH OF BED (STANDARD) 26'
DISTANCE BETWEEN FACE PLATES 19' EST.
MAXIMUM STROKE OF CRANKSHAFT 10"
FRONT SPINDLE BEARING 7" X 9"
REAR SPINDLE BEARING 6-1/2" X 7"
HEADSTOCK, BASE LENGTH 34-3/4"
TAILSTOCK, BASE LENGTH 34-3/4"
CARRIAGE BRIDGE WIDTH 20"
CARRIAGE LENGTH ON VEES 44"
MOTOR: RELIANCE, S.S. VARI-SPEED DRIVE 30 HP
WEIGHT APPROXIMATELY 50,000 LBS.
EQUIPPED WITH:
(2) 3-POSITION TURRET TYPE TOOL POSTS
POWER FEED CRANKSHAFT
TOOL PRESS SUPPORT
NEW AUTO OIL
NOTE: REBUILT IN MID 1995, LITTLE USE SINCE REBUILD
THEIR IS A 3 WAY TOOLPOST THAT REPLACES THE ELECTRIC LOOKING BOX ON THE SLIDE
