Specifications
Equipped With
GENERAL SPECIFICATIONS:
FLOOR TO SPINDLE CENTER HEIGHT 40"
X AXIS TRAVEL 11.75"
Z AXIS TRAVEL 8.5"
RAPID TRAVERSE RATE X AXIS 600 IPM
RAPID TRAVERSE RATE Z AXIS 600 IPM
MAXIMUM INTERPOLATED FEED RATE 250 IPM
SPINDLE NOSE A2-3
MAXIMUM BAR DIAMETER 1.06"
SPINDLE SPEEDS 0 - 4,500 RPM
SPINDLE MOTOR 5 HP
TOOLING CAPACITY 16" x 6" GANG TOOL PLATE
TOOLING SIZE 0.5" (1/2")
MACHINE WEIGHT 2,800 LBS
MACHINE DIMENSIONS 48" x 36" x 70"
EQUIPPED WITH:
FAGOR 8025T CNC CONTROL WITH 9" CRT & TEACH MODE
RS-232C PORT INTERFACE FOR DNC OPERATION & DNC READY
MIST LUBRICATED PNEUMATIC 5C COLLET CLOSER
TOOL PATH GRAPHICS, TOOL PATH INSPECTION
GRAPHIC ASSISTED CANNED CYCLE GENERATION
STANDARD COOLANT SYSTEM WITH TANK & PUMP
ALL AVAILABLE TOOL HOLDERS & MANUALS
