Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1994
BAR CAPACITY 1-3/8"
MAXIMUM LENGTH FEED-OUT 6-3/8"
NUMBER OF INDEPENDENT FEEDS 4
STROKE OF INDEPENDENT FEEDS 120MM
NUMBER OF CROSS SLIDES 6
STROKE OF CROSS SLIDE 2-1/4"
NUMBER ENDWORKING UNITS 6
STROKE OF ENDWORKING UNIT 120MM
PROGRAMMABLE SPINDLE SPEED 400-4000 RPM
PROGRAMMABLE PRODUCTION CYCLE 1-24 RPM
MOTOR RATING 22 KW
EQUIPPED WITH:
PICK OFF SPINDLE
BACK FINISH SLIDE, 1 POSITION
THREADING ATTACHMENT
LONGITUDINAL TURNING ATTACHMENT
WINTER THREAD ROLLER
MISCELLANEOUS COLLETS, PUSHERS AND TOOLING
STOCK REEF FOR BARS 12' LONG
CHIP CONVEYOR
PC PROGRAMMABLE
