Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 10" X 50"
MAXIMUM TABLE LOAD 850 LBS
SPINDLE NOSE TO TABLE TOP 2" - 20.25"
THROAT DISTANCE 2.24" - 23.74"
X AXIS TRAVEL 36"
Y AXIS TRAVEL 16"
Z AXIS TRAVEL 5.51"
RAM TRAVEL 2.25"
KNEE TRAVEL 16"
RAPID TRAVERSE RATE X AXIS 400 IPM
RAPID TRAVERSE RATE Y AXIS 400 IPM
RAPID TRAVERSE RATE Z AXIS 250 IPM
SPINDLE SPEEDS (2 RANGES VARIABLE) 75 - 3,800 RPM
SPINDLE TAPER # 40
SPINDLE MOTOR 5 HP AC
EQUIPPED WITH:
ANILAM 1100 CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
FULL 3-AXIS CONTOURING (HELICAL INTERPOLATION)
FLOPPY DISK DRIVE, COOLANT SYSTEM WITH TANK & PUMP
ALL AVAILABLE TOOLING, ALL AVAILABLE MANUALS
