Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 64.9" x 27.55"
MAXIMUM TABLE LOAD 2,640 LBS
SPINDLE NOSE TO TABLE TOP 7.87" - 35.43"
X AXIS TRAVEL 57.08"
Y AXIS TRAVEL 27.55"
Z AXIS TRAVEL 27.55"
RAPID TRAVERSE RATE X AXIS 560 IPM
RAPID TRAVERSE RATE Y AXIS 560 IPM
RAPID TRAVERSE RATE Z AXIS 480 IPM
CUTTING FEED RATE 0.1 - 200 IPM
SPINDLE SPEEDS (2 SPEED GEARED) 30 - 6,000 RPM
SPINDLE TAPER CAT 50
SPINDLE MOTOR (2 SPEED GEARED) 25 HP AC
TOOL CHANGER CAPACITY 32 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 4 SECONDS
EQUIPPED WITH:
FANUC OMD CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
PRE-WIRED FOR 4TH AXIS ROTARY TABLE
REMOTE PULSE GENERATOR (REMOTE HANDWHEEL)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
(21) CAT 50 TOOL HOLDERS & 1 TOOL CHANGING BLOCK
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
