Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1999 (3/2000 INSTALL)
STANDARD TURNING DIAMETER 8"
MAXIMUM TURNING DIAMETER 10.24"
MAXIMUM TURNING LENGTH 7.95"
X AXIS TRAVEL (EACH TURRET) 7.68"
Z1 AXIS TRAVEL (LEFT TURRET) 10.83"
Z2 AXIS TRAVEL (RIGHT SPINDLE) 32.28"
C AXIS INDEXING (EACH SPINDLE) 0.001º
RAPID TRAVERSE RATE X AXES 787 IPM
RAPID TRAVERSE RATE Z AXES 945 IPM
SPINDLE NOSE / BORE (EACH SPINDLE) A2-6 / 2.56"
SPINDLE SPEEDS (EACH SPINDLE) 50 - 5,000 RPM
SPINDLE MOTOR (EACH SPINDLE) 20 HP AC
TURRET CAPACITY (EACH, ALL LIVE) 12 STATION TURRET
LIVE TOOLING MOTOR (BOTH TURRETS) 5 HP AC
LIVE TOOLING SPEEDS (BOTH TURRETS) 50 - 3,600 RPM
EQUIPPED WITH:
FANUC 18TTC CNC CONTROL WITH 10.4" LCD CRT & RS-232C PORT
2 (8") 3-JAW HYDRAULIC CHUCKS, (2) TOOL PRESETTERS
AUTO PARTS CATCHER & PARTS EJECTOR, BARFEED INTERFACE
RIGID TAPPING, POLAR COORDINATE INTERPOLATION
CYLINDRICAL INTERPOLATION, CANNED CYCLES FOR DRILLING
RIGHT HAND DISCHARGE LIFT-UP TYPE CHIP CONVEYOR
ALL AVAILABLE LIVE TOOLING TOOL HOLDERS (APPROX. 5)
ALL AVAILABLE TOOL BLOCK HOLDERS & MANUALS
