Specifications
Equipped With
GENERAL SPECIFICATIONS:
NOMINAL TURNING DIAMETER / LENGTH 3.14" / 4.52"
MAXIMUM TURNING DIAMETER / LENGTH 6.496" / 8.00"
X AXIS TRAVEL / Z AXIS TRAVEL 4.724" / 9.055"
RAPID TRAVERSE RATE X AXIS 472 IPM
RAPID TRAVERSE RATE Z AXIS 708.7 IPM
SPINDLE NOSE / SPINDLE MOTOR A2-5 / 7.5 HP AC
SPINDLE BORE 1.81"
SPINDLE SPEEDS 3,500 RPM
TURRET CAPACITY 8 STATION TURRET
AUTO LOAD SYSTEM (COMPACT SERVO LOADER a60)
TYPE OF GRIPPERS DOUBLE SET
MAXIMUM WORK SIZE (DIA. x LENGTH) 2.36" x 1.96"
MAXIMUM WORKPIECE WEIGHT 2.2 LBS x 2
SHOULDER & ARM RAPID TRAVERSE RATES 2834.6 IPM
LOAD / UNLOAD TIME (MINIMUM) 4 SECONDS
EQUIPPED WITH:
FANUC 21TB CNC CONTROL WITH 10.4" LCD & RS-232C PORT
6" 3-JAW HYDRAULIC THROUGH HOLE CHUCK WITH JAWS
INBOUND CONVEYOR WITH SENSOR, BRACKET & SOFTWARE
DOUBLE LIFTER, OUTBOUND CONVEYOR, FULL AUTOLOADING SYSTEM
TOTAL COUNTER & PRESET COUNTER, STANDARD COOLANT SYSTEM
ALL AVAILABLE GRIPPER FINGERS & LOADER ACCESSORIES
RIGHT HAND DISCHARGE LIFT-UP TYPE CHIP CONVEYOR
ALL AVAILABLE TOOL BLOCK HOLDERS & ALL AVAILABLE MANUALS
