GENERAL SPECIFICATIONS:
MANUFACTURER........................ STOELTING INC
MODEL............................... OMF-212
SERIAL NUMBER....................... M434
PART CLEARANCE...................... 12" WIDE X 12" TALL
CONVEYOR
CAPACITY......................... 25 LBS PER LINEAR FOOT
LOAD HEIGHT...................... 36"
FLAT WIRE BELT................... 1" X 1" MESH X 3/8"
SPEED (DC VARIABLE).............. 2 - 12 FPM
STAGES.............................. 3
STAGE 1.......................... WASH
TANK CAPACITY.................. 200 GALLONS
PUMP........................... 60 GPM/80'HD/5HP
HEAT
TEMPERATURE.................. 140 DEGREES
TYPE......................... GAS
KW-BTU/HR.................... 150,000
STAGE 2.......................... RINSE
TANK CAPACITY................ 200 GALLONS
PUMP......................... 60 GPM/80'HD/5HP
HEAT
TEMPERATURE.................. 140 DEGREES
TYPE......................... GAS
KW-BTU/HR.................... 150,000
STAGE 3.......................... DRYER
BLOWER....................... 1100 CFM/.25 CSP/5HP
HEAT
TEMP......................... 250 DEGREES
TYPE......................... GAS
KW-BTU/HR.................... 500,000
CONSTRUCTION
FRAMES........................... PAINTED CARBON STEEL
TANKS............................ 14 GAUGE STAINLESS STEEL
CANOPIES......................... 14 GAUGE STAINLESS STEEL
DRYER CONSTRUCTION............... STAINLESS STEEL
CHIP BASKET..................... STAINLESS STEEL
PIPING........................... STAINLESS STEEL
SPRAY TUBES...................... STAINLESS STEEL
PUMPS............................ STAINLESS STEEL FITTED
FILTERS.......................... STAINLESS STEEL
FILTER BAR....................... 100 MICRON
DIMENSIONS
OVERALL.......................... 17' X 54" X 7'9"
CONVEYOR EXTENSION AT EACH END... 1'10"
WASH/RINSE....................... 8'
DRYER............................ 5'
CURRENT VOLTAGE..................... 460V/60HZ/3PH
FULL LOAD........................... 27.2 AMPS
