Specifications subject to verification
Hood Dimensions:
- O.D.: 23.5"D x 32"W x 24"H
- I.D.: 23.25"D x 30"W x 24"H
Hood Material:
- 16awg 304 Stainless Steel
- All Fasteners 304 Stainless Steel
Motor:
Fractional Horsepower
Weight:
Approx. 100 lbs.
Blower Dimensions:
13" L x 13" W x 14.5"
Approximate Inlet Velocities: Pre-filter & 99.97% HEPA Filter - 130 FPM High; 25 FPM Low
Pre-filter & Heavy-duty Carbon Filter - 115 FPM High; 20 FPM Low
Electrical:
115/1/60, 2 amps
220/1/50, .75 amps
Sound Level:
61 to 66 dba (Blower Speed: Low to High)
Max Operating Temperature:
Not to exceed 170 degrees Fahrenheit
