Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 61.02" x 29.13"
MAXIMUM TABLE LOAD 3,300 LBS
SPINDLE NOSE TO TABLE TOP 5.91" - 31.89"
X AXIS TRAVEL 60.24"
Y AXIS TRAVEL 29.13"
Z AXIS TRAVEL 25.98"
RAPID TRAVERSE RATE X AXIS 945 IPM
RAPID TRAVERSE RATE Y AXIS 945 IPM
RAPID TRAVERSE RATE Z AXIS 787 IPM
CUTTING FEED RATE 0.1 - 393.7 IPM
SPINDLE SPEEDS 25 - 8,000 RPM
SPINDLE TAPER CAT 50
SPINDLE MOTOR 15 HP AC
TOOL CHANGER CAPACITY 30 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 2.0 SECONDS
EQUIPPED WITH:
OKK NEOMATIC (MISTUBISHI) CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
ETHERNET INTERFACE, HIGH SPEED MACHINING MODE I
SOFT SCALE II ON X, Y & Z AXES & SPINDLE
SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
