Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 129.92" x 32.28"
MAXIMUM TABLE LOAD 6,600 LBS
SPINDLE NOSE TO TABLE TOP 7.87" - 33.07"
X AXIS TRAVEL 120.08"
Y AXIS TRAVEL 32.28"
Z AXIS TRAVEL 28.35"
RAPID TRAVERSE RATE X AXIS 630 IPM
RAPID TRAVERSE RATE Y AXIS 630 IPM
RAPID TRAVERSE RATE Z AXIS 630 IPM
CUTTING FEED RATE 0.1 - 393.7 IPM
SPINDLE SPEEDS 100 - 13,000 RPM
SPINDLE TAPER CAT 50
SPINDLE MOTOR 30 HP AC
TOOL CHANGER CAPACITY 30 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 2.5 SECONDS
EQUIPPED WITH:
OKK NEOMATIC (MISTUBISHI) CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
OPTIONAL 1000 PSI CHIP BLASTER STYLE COOLANT THROUGH
OPTIONAL 13000 RPM 30 HP GEARED SPINDLE
SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM)
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
