Specifications
Equipped With
GENERAL SPECIFICATIONS:
MODEL MT
SERIAL # 315A0179-0033
NEW APPROXIMATELY 1979
WORKHEAD SWING OVER MAIN SLIDE 12"
DIST. BETWEEN SPDL. NOSE &
TAIL STOCK CTR. 6"
WORKHEAD MAX. COLLECT DIA. 1.25"
MAX. GRINDING WHEEL SIZE 4"
GRINDING WHEEL SPEED (RPM) 4000, 5729 & 8000
MIN. LEAD GENERATED BY LEAD MECH. 1.81"
WORKHEAD LONGITUDINAL SLIDE MVMT. 5.75"
WORKHEAD CROSS SLIDE MVMT. 5.25"
CROSS SLIDE FRONT OF CENTER 3"
CROSS SLIDE REAR OF CENTER 2.25"
WORKHEAD TURNTABLE SWIVEL 235 DEGREES
WORKHEAD VERTICAL TILT 80 DEGREES
ABOVE AND BELOW CENTER 40 DEGREES
WORKHEAD SPINDLE ROTATION 360 DEGREES
WHEELHEAD LONGITUDINAL SLIDE MVMT. 6"
WHEELHEAD CROSS SLIDE MVMT. 7.5"
WHEELHEAD VERTICAL SLIDE MVMT. 9.5"
ABOVE CENTER 4.5"
BELOW CENTER 5"
WORKHEAD SPINDLE SPEED 436 RPM
MACHINE WEIGHT 1550 LBS
EQUIPPED WITH:
MOTORIZED WORKHEAD
ADJUSTABLE CENTER SUPPORT SPING
1 HP GRINDER SPINDLE MOTOR
