Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1986
SERIAL 75200
SPINDLE WITH JAW CHUCKS 6"
CAPACITY WITH EXPANDING COLLETS 3"
ROUND 5C COLLETS 1-1/16"
HEXAGON 5C COLLETS 7/8"
STEP CHUCKS 1-1/16" - 6"
SPINDLE NOSE DIAMETER 2.189"
SPINDLE NOSE THREAD 2-3/16", 10 R.H.
SPINDLE SPEEDS 135-2955 RPM
CARRIAGE POWER FEED RANGE (PER MINUTE) 1/4"-10"
CROSS SLIDE POWER FEED RANGE (PER MINUTE) 11/32"-6-1/4"
TRAVEL OF SLIDE 4-1/2"
TRAVEL OF DOUBLE TOOL CROSS SLIDE 3-3/4"
LENGTH OF BED 43-1/2"
MAXIMUM FIXTURE DIAMETER 9"
MAXIMUM DISTANCE FROM FACE TO TURRET
TO SPINDLE 14"
EQUIPPED WITH:
8 STATION TURRET TEMPORARY SPECIFICATIONS SUBJECT TO VERIFICATION
