No. 4, KEARNEY & TRECKER, 18" x 82" TBL, 1300 RPM, 50 TAPER, 15 HP, VERT. HEAD ATTACH., 1943

GENERAL SPECIFICATIONS:
SERIAL 154060
NEW APPROXIMATELY 1943
MODEL K
TABLE SIZE 18" X 82"
TRAVELS (POWER LONGITUDINAL) 42"
(POWER CROSS) 14"
(POWER VERTICAL) 20"
SPINDLE TAPER NO. 50
SPINDLE SPEEDS (24) WITH REVERSE 13-1300 RPM
FEEDS (32) (LONGITUDINAL & CROSS) 1/4"-60" IPM
(VERTICAL) 1/8"-30" IPM
HORSE POWER 15
WEIGHT 12,500 LBS.
DIMENSIONS 52" X 97" X 75"

EQUIPPED WITH:
ARBOR SUPPORTS
COOLANT
