Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1950
DIAMETER OF CAPACITY: NOMINAL 1"-4"
: MAXIMUM 10"
GRINDING WHEEL DIAMETER: MINIMUM 16"
: MAXIMUM 24"
GRINDING WHEEL WIDTH: MINIMUM 8"
: MAXIMUM 12"
GRINDING WHEEL HOLE DIAMETER 12"
REGULATING WHEEL DIAMETER: MINIMUM 10.25"
: MAXIMUM 14"
REGULATING WHEEL WIDTH: MINIMUM 8"
: MAXIMUM 12"
REGULATING WHEEL HOLE DIAMETER 5"
(10) REGULATING WHEEL SPEEDS, RANGE 7-57 RPM
GRINDING WHEEL MOTOR, HP/RPM 30 HP/1170 RPM
ELECTRICAL SYSTEM 440/3/60
DIMENSIONS APPROXIMATELY 8.5' x 5' x 5'
WEIGHT APPROXIMATELY 14,000 LBS.
EQUIPPED WITH:
HYDRAULIC PROFILE DRESSERS ON BOTH WHEELS
PLUNGE ATTACHMENT TEMPORARY SPECIFICATIONS SUBJECT TO VERIFICATION
