Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER O.K.
MODEL 202
SERIAL # K77128
DIAMETER OF SWING 12"
LENGTH BETWEEN CNTRS FOOTSTOCK & WORK HEAD 21"
LENGTH BETWEEN RIGHT & LEFT FOOTSTOCK CNTRS 27"
BARE MILL CAPACITY 12"
TABLE SURFACE 5-1/4" x 36"
LONGTIDINAL TABLE MOVEMENT 17-1/2"
DISTANCE BETWEEN WHEEL & WORK CENTERS 0" - 11-1/2"
HEIGHT OF WORK CENTERS ABOVE FLOOR 48"
DIMENSIONS (APPROX.) 62" x 72"
WHEEL DRIVE MOTOR 1 HP
WHEEL DRIVE SPEED 3600 RPM
WORK DRIVE MOTOR 1/4 HP
WORK DRIVE SPEED 1800 RPM
WHEEL HEAD TILTS EACH WAY 15 DEG.
WHEEL HEAD SWIVELS 360 DEG.
SPINDLE SPEED 4050 & 6060 RPM
VERTICAL MOVEMENT OF WHEEL HEAD
ABOVE CENTER OF WORK 8-1/2"
BELOW CENTER OF WORK 2-1/2"
MAX. VERT. DIST. SPINDLE CNTR TO TABLE TOP 14-1/4"
CROSS MOVEMENT OF WHEEL SLIDE 8-1/2"
ELECTRICS 220V/3 PH
