Specifications
Equipped With
#98160-7
GENERAL SPECIFICATIONS:
NEW APPROXIMATELY 1975
SERIAL 4700-110075
MAX. WORK DIAMETER 16"
MAX. FACE WIDTH 10"
MAX. MOUNTABLE HOB DIAMETER 6-1/2"
MAX. MOUNTABLE HOB LENGTH 7"
WORKSLIDE TRAVEL (HORIZONTAL):
DISTANCE CENTER LINE OF WORK SPINDLE
TO CENTER LINE OF HOB SPINDLE 2" MIN.
11-1/4" MAX.
HOB CARRIAGE TRAVEL (VERTICAL):
DISTANCE, CENTERLINE OF HOB SPINDLE
TO FACE OF WORK SPINDLE 5-3/8" MIN
17-3/8" MAX.
MAX. HOB SLIDE TRAVEL (SHIFTING):
WORK TABLE DIMENSIONS:
OD 16"
BORE DIAMETER 5-1/2"
INDEX WORM GEAR DIAMETER 17-3/16"
EQUIPPED WITH:
CROWING
CHANGE GEARS
MAIN DRIVE MOTOR 10 HP
HYDRAULIC PUMP MOTOR 2 HP
RAPID TRAVERSE 3 HP
COOLANT PUMP 1 HP
LUBRICATION PUMP 1/4 HP
WEIGHT APPROXIMATELY 18,000 LBS.
