Specifications
Equipped With
#98161-7
GENERAL SPECIFICATIONS:
SERIAL 4700-11086
NEW APPROXIMATELY 1975
MAX. WORK DIAMETER 16"
MAX. FACE WIDTH 10"
MAX. MOUNTABLE HOB DIAMETER 6-1/2"
MAX. MOUNTABLE HOB LENGTH 7"
WORKSLIDE TRAVEL (HORIZONTAL)
DISTANCE CENTERLINE OF WORK SPINDLE
TO CENTER LINE OF HOB SPINDLE
MINIMUM 2"
MAXIMUM 11-1/4"
HOB CARRIAGE TRAVEL (VERTICAL)
DISTANCE CENTERLINE OF HOB SPINDLE
TO FACE OF WORK SPINDLE
MINIMUM 5-3/8"
MAXIMUM 17-3/8"
MAX. HOBSIDE TRAVEL (SHIFTING):
WORK TABLE DIMENSIONS:
O.D. 16"
BORE DIAMETER 5-1/2"
INDEX WORM GEAR DIAMETER 17-3/16"
EQUIPPED WITH:
CROWNING
CHANGE GEARS
MAIN DRIVE MOTOR 10 HP
HYDRAULIC PUMP MOTOR 2 HP
RAPID TRAVERSE 3 HP
COOLANT PUMP 1 HP
LUBRICATION PUMP 1/4 HP
WEIGHT APPROXIMATELY 18,000 LBS.
WE QUOTED YOU THIS MACHINE FOR 37,500. WE HAVE TWO OF THESE
WHICH WE WILL SELL FOR 9,950 EACH. WE ARE TRYING TO CLEAR OUT
ONE WAREHOUSE.
