Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER........................ NICHOLS
MODEL............................... NO. 8
TABLE SIZE.......................... 7" X 24"
X TABLE TRAVEL...................... 8"
Y TABLE TRAVEL...................... 6"
VERTICAL KNEE TRAVEL................ 11"
DISTANCE TABLE TO SPINDLE CENTER.... 11 1/4"
SPINDLE SPEEDS...................... 60-2875 RPM
SPINDLE TAPER....................... 40
WEIGHT (APPROX.).................... 1,500 LBS
ELECTRICS:.......................... 240 VOLTS
EQUIPPED WITH:
LONGITUDINAL PNEUMATIC TABLE FEED
PNEUMATIC VERTICAL SPINDLE FEED
3 AUTO CYCLES
HEAD DOWN/TABLE FEED/HEAD UP/TABLE RETURN
HEAD DOWN/HEAD UP
TABLE FEED/TABLE RETURN
PUSH BUTTON CONTROL STATION
COOLANT
CHIP PAN
LUBE SYSTEM
SPECIFICATIONS SUBJECT TO VERIFICATION
