Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING SLIDE COVERS (EACH SPINDLE) 10.63"
STD. / MAX. TURNING DIAMETER (EACH) 6.5" / 10.63"
STD. / MAX. TURNING LENGTH (EACH) 4.82" / 7.87"
X1 AXIS TRAVEL 6.89"
X2 AXIS TRAVEL 6.89"
Z1 AXIS TRAVEL 9.45"
Z2 AXIS TRAVEL 26.77"
RAPID TRAVERSE RATE X AXES 472 IPM
RAPID TRAVERSE RATE Z AXES 945 IPM
SPINDLE NOSE (EACH SPINDLE) A2-6
SPINDLE BORE (BOTH SPINDLES) 2.44"
MAXIMUM BAR CAPACITY (ROUND, BOTH) 2"
SPINDLE SPEEDS (EACH SPINDLE) 50 - 5,000 RPM
SPINDLE MOTOR (EACH SPINDLE) 20 HP AC
LEFT TURRET CAPACITY 12 STATION TURRET
RIGHT TURRET CAPACITY 12 STATION TURRET
EQUIPPED WITH:
FANUC 16TTA 4-AXIS CNC CONTROL WITH 10" LCD & RS-232C PORT
8" CHUCK ON LEFT SPINDLE, 16C COLLET ON RIGHT SPINDLE
TOOL EYE (TOOL LENGTH MEASUREMENT SYSTEM) ON EACH SPINDLE
PANASONIC ROBOTIC LOADING SYSTEM, PARTS OFFLOAD CONVEYOR
AUTO DOOR, AIR BLOW, SPINDLE ORIENTATION, NT NURSE
STANDARD COOLANT SYSTEM WITH TANK & PUMP, PARTS CATCHER
RIGHT HAND DISCHARGE LIFT-UP TYPE CHIP CONVEYOR
ALL AVAILABLE TOOL HOLDERS, ALL AVAILABLE MANUALS
