Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 27.55"
MAXIMUM TURNING DIAMETER 15.35"
MAXIMUM TURNING LENGTH 24.21"
X1 AXIS TRAVEL 9.25"
X2 AXIS TRAVEL 6.7"
Z1 & Z2 AXIS TRAVEL 25.59"
RAPID TRAVERSE RATE X AXES 708 IPM
RAPID TRAVERSE RATE Z AXES 945 IPM
SPINDLE NOSE A2-8
SPINDLE BORE 3.38"
MAXIMUM BAR CAPACITY (ROUND) 2.87"
SPINDLE SPEEDS 35 - 3,500 RPM
SPINDLE MOTOR 30 HP AC
UPPER TURRET CAPACITY 12 STATION TURRET
LOWER TURRET CAPACITY 8 STATION TURRET
TAILSTOCK BODY TRAVEL 19.6"
TAILSTOCK QUILL TAPER MT #5
TAILSTOCK QUILL TRAVEL / DIAMETER 4.72" / 4.33"
EQUIPPED WITH:
MORI MSC-501 CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
COLLET CHUCK SYSTEM, 8 ADDITIONAL M FUNCTIONS
TOOL EYE (TOOL LENGTH MEASUREMENT SYSTEM)
AUTO DOOR, AIR BLOW, SPINDLE ORIENTATION
STANDARD COOLANT SYSTEM WITH TANK & PUMP
RIGHT HAND DISCHARGE CHIP CONVEYOR
ALL AVAILABLE TOOL HOLDERS & MANUALS
