Specifications
Equipped With
GENERAL SPECIFICATIONS:
PALLET SIZE 15.75" X 15.75"
PALLET CHANGE TIME 5 SECONDS (7 SECONDS)
MAXIMUM TABLE LOAD (W/7 SEC APC) 660 LBS (1,100 LBS)
SPINDLE NOSE TO PALLET CENTER 3.9" - 24.0"
SPINDLE CENTER TO PALLET SURFACE 2.0" - 22.0"
X AXIS TRAVEL 22"
Y AXIS TRAVEL 20.1"
Z AXIS TRAVEL 20.1"
B AXIS INDEXING 0.001º
RAPID TRAVERSE RATE X, Y & Z AXES 1260 IPM
CUTTING FEED RATE 0.01 - 944.9 IPM
SPINDLE SPEEDS 50 - 12,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 30 HP AC
TOOL CHANGER CAPACITY 40 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 1.5 SECONDS
EQUIPPED WITH:
FANUC 18M CNC CONTROL WITH 10.4" LCD CRT & RS-232C PORT
RIGID TAP, HI PRESSURE COOLANT THROUGH THE SPINDLE (625 PSI)
OVERHEAD SHOWER COOLANT & OIL HOLE COOLANT SYSTEMS
640 METERS PROGRAM STORAGE MEMORY, INTERNAL SPIRAL CONVEYORS
SPINDLE OIL COOLING SYSTEM (SPINDLE OIL CHILLER)
FULL CONTOURING ROTARY B-AXIS, EXTERNAL CHIP CONVEYOR
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
