Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER MORI SEIKI
MODEL NH5000/40
NEW (APPROX.) 2003
SERIAL NH501CC0278
X-AXIS TRVL (LONGITUDINAL) 24.8"
Y-AXIS TRVL (VERTICAL) 23.6"
Z-AXIS TRVL (CROSS) 26.4"
PALLET WORKING SURFACE 19.7" x 19.7"
PALLET LOADING CAPACITY 1,100 LBS
TABLE MAX. WORK PIECE SWING DIA. 28.7"
MAX. WORK PIECE HEIGHT 35.4"
SPINDLE SPEEDS 14,000 RPM
TOOL SHANK BT40
TOOL STORAGE CAPACITY 60
COOLANT TANK CAPACITY 142.6 GALLONS
DIMENSIONS-NO CHIP CONVEYOR (APPROX.) 92.5"x192.9"x112.2"H
WEIGHT (APPROX.) 22,000 LBS.
EQUIPPED WITH:
AUTOMATIC TOOL CHANGER
CHIP CONVEYOR
1100 CUTTING HOURS
THROUGH SPINDLE COOLANT
