Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 74.8" x 31.5"
MAXIMUM TABLE LOAD 4,409 LBS
SPINDLE NOSE TO TABLE TOP 7.87" - 37.4"
X AXIS TRAVEL 60"
Y AXIS TRAVEL 31.5"
Z AXIS TRAVEL 29.53"
RAPID TRAVERSE RATE X, Y & Z AXES 394 IPM
CUTTING FEED RATE 0.04 - 140 IPM
SPINDLE SPEEDS 10 - 3,150 RPM
SPINDLE TAPER # 50
SPINDLE MOTOR 20 HP AC
TOOL CHANGER CAPACITY 32 STATION ATC
MAXIMUM TOOL WEIGHT 44 LBS
MAXIMUM TOOL LENGTH 15.75"
EQUIPPED WITH:
FANUC 6MB CNC CONTROL WITH 9" MONOCHROME CRT
RS-232 PORT INTERFACE FOR DNC OPERATION
MANUAL PULSE GENERATOR, HELICAL INTERPOLATION
SPINDLE OIL COOLING SYSTEM (SPINDLE CHILLER)
CUTTING OIL UNIT, OIL SHOT UNIT, BUILT IN WORK LIGHT
STANDARD COOLANT SYSTEM WITH TANK & PUMP
EXTENDED HEIGHT TABLE GUARDING, ALL AVAILABLE MANUALS
