Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 86.5" x 36"
MAXIMUM TABLE LOAD 6,000 LBS
SPINDLE NOSE TO TABLE TOP 5" - 31"
X AXIS TRAVEL 76"
Y AXIS TRAVEL 36"
Z AXIS TRAVEL 26"
RAPID TRAVERSE RATE X AXIS 600 IPM
RAPID TRAVERSE RATE Y AXIS 600 IPM
RAPID TRAVERSE RATE Z AXIS 600 IPM
CUTTING FEED RATE 0.04 - 400 IPM
SPINDLE SPEEDS 30 - 6,000 RPM
SPINDLE TAPER CAT 50
SPINDLE MOTOR (2 SPEED GEARED) 30 HP AC
TOOL CHANGER CAPACITY 30 STATION ATC
MAXIMUM TOOL WEIGHT 25 LBS
EQUIPPED WITH:
FANUC 15MF CONVERSTAIONAL CNC CONTROL WITH 14" COLOR CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
HIGH PRESSURE COOLANT THROUGH THE TOOL
TOUCH PROBE W/PREDEFINED CYCLES & COORDINATE ROTATION
SPINDLE OIL COOLING SYSTEM (SPINDLE CHILLER)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
TOOL TOUCH PROBE, SCALES ON X, Y & Z AXES
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
