Specifications
Equipped With
GENERAL SPECIFICATIONS:
MAXIMUM SWING 12.6"
MAXIMUM TURNING DIAMETER / LENGTH 2.75" / 3.15"
X AXIS TRAVEL / Z AXIS TRAVEL 9.45" / 7.5"
RAPID TRAVERSE RATE X AXIS 630 IPM
RAPID TRAVERSE RATE Z AXIS 708.7 IPM
SPINDLE NOSE / SPINDLE MOTOR FLAT / 10 HP AC
SPINDLE SPEEDS 60 - 6,000 RPM
TURRET CAPACITY 8 STATION TURRET
TURRET INDEX TIME 0.3 SECONDS
AUTO LOAD SYSTEM
TYPE OF GRIPPERS DOUBLE SET
MAXIMUM WORK SIZE (DIA. x LENGTH) 2.75" x 3.15"
MINIMUM WORK SIZE (DIA. x LENGTH) 0.4" x 0.4"
MAXIMUM WORKPIECE WEIGHT 1.54 LBS x 2
MAXIMUM GRIPPER WEIGHT 3.3 LBS x 2
MAX. GRIPPER / LAODER SLIDE STROKE 1.57" / 9.84"
LOAD / UNLOAD TIME (MINIMUM) 4 SECONDS
EQUIPPED WITH:
FANUC 21TB CNC CONTROL WITH 10.4" LCD & RS-232C PORT
6" 3-JAW HYDRAULIC CHUCK WITH JAWS, HIGH PRESSURE COOLANT
INBOUND CONVEYOR WITH SENSOR, BRACKET & SOFTWARE
DOUBLE LIFTER, OUTBOUND CONVEYOR, FULL AUTOLOADING SYSTEM
TOTAL COUNTER & PRESET COUNTER, STANDARD COOLANT SYSTEM
ALL AVAILABLE GRIPPER FINGERS & LOADER ACCESSORIES
ALL AVAILABLE TOOL BLOCK HOLDERS & ALL AVAILABLE MANUALS
