Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 13.75"
MAXIMUM TURNING DIAMETER 8"
MAXIMUM TURNING LENGTH 11.62"
X AXIS TRAVEL 6.5"
X AXIS TRAVEL 13.75"
C AXIS INDEXING 0.001 DEG.
RAPID TRAVERSE RATE X AXES 551 IPM
RAPID TRAVERSE RATE Z AXES 630 IPM
SPINDLE NOSE A2-6
SPINDLE BORE 2.4"
MAXIMUM BAR CAPACITY (ROUND) 2"
SPINDLE SPEEDS 25 - 4,000 RPM
SPINDLE MOTOR 25 HP AC
TURRET CAPACITY (5 LIVE STATIONS) 10 STATION TURRET
LIVE TOOLING MOTOR 3 HP
LIVE TOOLING SPEEDS 100 - 3,000 RPM
TAILSTOCK QUILL TAPER MT #4
TAILSTOCK QUILL TRAVEL 4.72
EQUIPPED WITH:
FANUC 0T CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
COLLET CHUCK SYSTEM, 16 ADDITIONAL OFFSETS
FMB MINI-TURBO MAGAZINE BARFEED SYSTEM (12')
AUTO PARTS CATCHER, PARTS OFFLOADING CONVEYOR
STANDARD COOLANT SYSTEM WITH TANK & PUMP
REAR OF MACHINE DISCHARGE CHIP CONVEYOR
ALL AVAILABLE LIVE TOOL HOLDERS (4)
ALL AVAILABLE TOOL HOLDERS & MANUALS
