Specifications
Equipped With
GENERAL SPECIFICATIONS:
MAXIMUM BAR CAPACITY (ROUND) 1.31"
STANDARD TURNING DIAMETER 8.06"
MAXIMUM TURNING LENGTH 4.87"
X AXIS TRAVEL 5.5"
Z AXIS TRAVEL 8.25"
B AXIS TRAVEL (SUB SPINDLE PICKOFF) 11.18"
C AXIS INDEXING (MAIN & SUB SPINDLE) 7.5º
RAPID TRAVERSE RATE X AXIS 472 IPM
RAPID TRAVERSE RATE Z AXIS 472 IPM
SPINDLE NOSE (MAIN / SUB SPINDLE) A2-5 / FLAT
MAIN SPINDLE SPEEDS 170 - 5,000 RPM
SUB SPINDLE SPEEDS 170 - 5,000 RPM
SPINDLE MOTOR (MAIN / SUB SPINDLE) 10 / 3 HP AC
TURRET CAPACITY (4 STATIONS LIVE) 8 STATION TURRET
LIVE TOOLING MOTOR 3 HP
LIVE TOOLING SPEEDS 100 - 3,000 RPM
EQUIPPED WITH:
FANUC 0TC CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
S-16 COLLET ON MAIN, 5C COLLET ON SUB
C-AXIS WITH SYNCHRONIZED SPINDLES FOR PICKOFF
LNS HYDROBAR FULL LENGTH 12' BARFEED SYSTEM
PARTS CATCHER, PARTS OFFLOADING CONVEYOR
MAIN SPINDLE MOUNTED CUTOFF CONFIRMATION SENSOR
RIGHT HAND DISCHARGE CHIP CONVEYOR
ALL AVAILABLE TOOL HOLDERS & MANUALS
