GENERAL SPECIFICATIONS:
TABLE SIZE 107.87" x 29.35"
MAXIMUM TABLE LOAD 6,600 LBS
SPINDLE NOSE TO TABLE TOP 7.8" - 37.4"
X AXIS TRAVEL 102.36"
Y AXIS TRAVEL 31.89"
Z AXIS TRAVEL 29.53"
RAPID TRAVERSE RATE X AXIS 472 IPM
RAPID TRAVERSE RATE Y AXIS 472 IPM
RAPID TRAVERSE RATE Z AXIS 393 IPM
CUTTING FEED RATE 0.1 - 150 IPM
SPINDLE SPEEDS (2 SPEED GEARED) 20 - 4,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 25 HP
TOOL CHANGER CAPACITY 80 STATION ATC
MAXIMUM TOOL WEIGHT 44 LBS
MACHINE DIMENSIONS (L x W x H) 115" x 137" x 142"
EQUIPPED WITH:
MAZATROL M-2 CONVERSATIONAL CNC CONTROL WITH 9" COLOR CRT
RS-232C PORT INTERFACE, PRE-WIRED FOR 4TH AXIS ROTARY
TOOL LIFE MANAGEMENT, TOOL BREAKAGE DETECTION, MIRROR IMAGE
PREPPED FOR COOLANT THROUGH THE SPINDLE, FLOOD COOLANT
REMOTE PULSE GENERATOR, ADAPTIVE FEEDRATE CONTROL, EIA/ISO
PITCH ERROR COMP, EXTENDED 80 STATION ATUO TOOL CHANGER
FULLY ENCLOSED SPLASH GUARDING, ALL AVAILABLE MANUALS
