Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 20"
SWING OVER CROSS SLIDE 15.75"
MAXIMUM TURNING DIAMETER 12.5"
MAXIMUM TURNING LENGTH (SHAFT WORK) 39.4"
X AXIS TRAVEL 7.875"
Z AXIS TRAVEL 40.1"
RAPID TRAVERSE RATE X AXIS 472 IPM
RAPID TRAVERSE RATE Z AXIS 944 IPM
SPINDLE NOSE A2-8
SPINDLE BORE 3.15"
SPINDLE SPEEDS 30 - 3,000 RPM
SPINDLE MOTOR 30 HP AC
TURRET CAPACITY 16 STATION TURRET
TAILSTOCK BODY TRAVEL 32.85"
TAILSTOCK QUILL TRAVEL / DIAMETER 5.12" / 3.94"
EQUIPPED WITH:
MAZATROL T-2 CONVERSATIONAL CNC CONTROL W/9" COLOR CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
10" 3-JAW HYDRAULIC CHUCK WITH JAWS
TOOL EYE / TOOL PRESETTER, MULTI-TAP TRANSFORMER
STANDARD COOLANT SYSTEM WITH TANK & PUMP
RIGHT HAND DISCHARGE CHIP CONVEYOR
ALL AVAILABLE TOOLING, ALL AVAILABLE MANUALS
