Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 24"
MAXIMUM TURNING DIAMETER 22.8"
MAXIMUM TURNING LENGTH (SHAFT WORK) 13.75"
X AXIS TRAVEL 21.25"
Z AXIS TRAVEL 121"
RAPID TRAVERSE RATE X / Z AXIS 472 IPM / 551 IPM
SPINDLE NOSE A2-11
SPINDLE BORE 4.1"
MAXIMUM BAR CAPACITY 3.5"
SPINDLE SPEEDS (3 SPEED GEARED) 6 - 2,200 RPM
SPINDLE MOTOR 30 HP AC
TURRET CAPACITY (FRONT) 8 STATION OCTAGONAL
TURRET CAPACITY (REAR) 6 STATION HEXAGONAL
TAILSTOCK QUILL TRAVEL / DIAMETER 5.12" / 4.0"
EQUIPPED WITH:
MAZATROL T-PLUS CONVERSATIONAL CNC CONTROL W/12" CRT
RS-232C PORT INTERFACE FOR DNC (OFFLINE PROGRAMMING)
15" 3-JAW HYDRAULIC THROUGH HOLE CHUCK WITH JAWS
EIA / ISO G-CODE PROGRAMMING, MANUAL STEADY REST
STANDARD COOLANT SYSTEM WITH TANK & PUMP
RIGHT HAND DISCHARGE LIFT-UP TYPE CHIP CONVEYOR
ALL AVAILABLE TOOLING, ALL AVAILABLE MANUALS
