Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 22"
MAXIMUM TURNING DIAMETER 16.5"
MAXIMUM TURNING LENGTH (SHAFT WORK) 11.75"
X AXIS TRAVEL 21.25"
Z AXIS TRAVEL 60.2"
RAPID TRAVERSE RATE X AXIS 597 IPM
RAPID TRAVERSE RATE Z AXIS 597 IPM
SPINDLE NOSE A2-8
SPINDLE BORE 3.45"
MAXIMUM BAR CAPACITY 3"
SPINDLE SPEEDS (3 SPEED GEARED) 6 - 3,000 RPM
SPINDLE MOTOR 25 HP AC
TURRET CAPACITY (FRONT) 8 STATION OCTAGONAL
TURRET CAPACITY (REAR) 6 STATION HEXAGONAL
TAILSTOCK QUILL TRAVEL 5.12"
TAILSTOCK QUILL DIAMETER 3.15"
EQUIPPED WITH:
MAZATROL T-PLUS CONVERSATIONAL CNC CONTROL W/12" CRT
RS-232C PORT INTERFACE FOR DNC (OFFLINE PROGRAMMING)
8" 3-JAW HYDRAULIC THROUGH HOLE CHUCK WITH JAWS
STANDARD COOLANT SYSTEM WITH TANK & PUMP
RIGHT HAND DISCHARGE LIFT-UP TYPE CHIP CONVEYOR
ALL AVAILABLE TOOLING, ALL AVAILABLE MANUALS
