Specifications
Equipped With
GENERAL SPECIFICATIONS:
PALLET SIZE 19.7" x 19.7"
NUMBER OF PALLETS 6
MAXIMUM TABLE LOAD 1,100 LBS
SPINDLE NOSE TO PALLET CENTER 1.97" - 20.9"
SPINDLE CENTER TO PALLET SURFACE 5.9" - 26"
X AXIS TRAVEL 27.92"
Y AXIS TRAVEL 18.11"
Z AXIS TRAVEL 20.08"
B AXIS INDEXING 1 DEG.
RAPID TRAVERSE RATE X AXIS 945 IPM
RAPID TRAVERSE RATE Y AXIS 945 IPM
RAPID TRAVERSE RATE Z AXIS 945 IPM
CUTTING FEED RATE 0.1 - 393 IPM
SPINDLE SPEEDS 70 - 7,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 20 HP AC
TOOL CHANGER CAPACITY 160 STATION ATC
MAXIMUM TOOL WEIGHT 26.4 LBS
EQUIPPED WITH:
MAZATROL M-32-2 CONVERSATIONAL CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
COOLANT THROUGH THE SPINDLE (220 PSI)
TOOL LIFE MONITORING, AUTO TOOL LENGTH MEASUREMENT
FACTORY INSTALLED 6 PALLET CHANGER, AIR BLAST
RIGHT HAND DISCHARGE CHIP CONVEYOR
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
