Specifications
Equipped With
GENERAL SPECIFICATIONS:
PALLET SIZE (2 PALLETS) 19.68" x 19.68"
MAXIMUM PALLET LOAD 2,200 LBS
PALLET CHANGE TIME 5 SECONDS
SPINDLE NOSE TO PALLET CENTER 5.91" - 361.89"
SPINDLE CENTER TO PALLET SURFACE 1.96" - 25.98"
X AXIS TRAVEL 27.95"
Y AXIS TRAVEL 24.02"
Z AXIS TRAVEL 25.98"
RAPID TRAVERSE RATE X, Y & Z AXES 1300 IPM
CUTTING FEED RATE 0.1 - 1300 IPM
SPINDLE SPEEDS 25,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 30 HP AC
TOOL CHANGER CAPACITY 60 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 1.3 SECONDS
EQUIPPED WITH:
MAZATROL M-PLUS CONVERSATIONAL CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION, EIA/ISO OPTION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING), EIA 3D COMP
HIGH PRESSURE COOLANT THROUGH THE SPINDLE, SCALING, SPIRAL
TOOL LIFE MONITORING, MONITORING SYSTEM B (PREPPED FOR PROBE)
AUTO TOOL LENGTH MEASUREMENT, TOOL BREAKAGE DETECTION
ADAPTIVE FEEDRATE CONTROL, HIGH SPEED SHAPE COMP, EXT. DATA
CHIP CONVEYOR, FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
