Specifications
Equipped With
GENERAL SPECIFICATIONS:
NEW 2001
PALLET SIZE 15.74" x 15.74"
MAXIMUM TABLE LOAD 661 LBS
NO. OF PALLETS / PALLET CHANGE TIME 2 / 6.3 SECONDS
SPINDLE NOSE TO PALLET CENTER 3.93" - 24.01"
SPINDLE CENTER TO PALLET SURFACE 4.72" - 29.52"
X AXIS TRAVEL 22.04"
Y AXIS TRAVEL 20.07"
Z AXIS TRAVEL 24.83"
RAPID TRAVERSE RATE X, Y & Z AXES 1417 IPM
CUTTING FEED RATE 0.1 - 1417 IPM
SPINDLE SPEEDS 50 - 12,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 30 HP AC
TOOL CHANGER CAPACITY 40 STATION ATC
TOOL CHANGE TIME (CHIP TO CHIP) 3.5 SECONDS
EQUIPPED WITH:
MAZATROL FUSION 640M CONVERSATIONAL CNC CONTROL WITH 10" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
COOLANT THROUGH THE SPINDLE (220 PSI)
TOOL LIFE MONITORING, MAZAK MONITORING SYSTEM
AUTO TOOL LENGTH MEASUREMENT, TOOL BREAKAGE DETECTION
ADAPTIVE FEEDRATE CONTROL, 3.5" FLOPPY DRIVE
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
