Specifications
Equipped With
GENERAL SPECIFICATIONS:
PALLET SIZE 15.75" X 15.75"
MAXIMUM TABLE LOAD 880 LBS
PALLET CHANGE TIME 10 SECONDS
SPINDLE NOSE TO PALLET CENTER 3.9" - 25.5"
SPINDLE CENTER TO PALLET SURFACE 3.1" - 24.8"
X AXIS TRAVEL 23.6"
Y AXIS TRAVEL 21.6"
Z AXIS TRAVEL 21.6"
B AXIS INDEXING 0.001 DEG.
RAPID TRAVERSE RATE X, Y & Z AXES 945 IPM
CUTTING FEED RATE 0.1 - 393.7 IPM
SPINDLE SPEEDS 15,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR 15 HP AC
TOOL CHANGER CAPACITY 60 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 2.4 SECONDS
EQUIPPED WITH:
YASNAC I80M CNC CONTROL WITH 9" MONOCHROME CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
COOLANT THROUGH THE SPINDLE (220 PSI)
EXTERNAL LIFT-UP TYPE CHIP REMOVAL CONVEYOR
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
