Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 21.7" x 12.6"
MAXIMUM TABLE LOAD 550 LBS
X AXIS TRAVEL 21.7"
Y AXIS TRAVEL 12.6"
Z AXIS TRAVEL 13.8"
RAPID TRAVERSE RATE X AXIS 472 IPM
RAPID TRAVERSE RATE Y AXIS 472 IPM
RAPID TRAVERSE RATE Z AXIS 315 IPM
CUTTING FEED RATE 0.1 - 200 IPM
SPINDLE SPEEDS 0 - 4,500 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR (VECTOR DRIVE) 7.5 HP
EQUIPPED WITH:
HAAS 32-BIT CNC CONTROL WITH 12" CRT & REMOTE JOG HANDLE
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SOLID TAPPING), COORDINATE ROTATION & SCALING
PROGRAMMABLE COOLANT NOZZLE, QUIKCODE PROGRAMMING
INTERNAL CHIP CONVEYOR, FLOPPY DISK DRIVE, WIRED FOR 4TH AXIS
CUSTOM MACROS, STANDARD COOLANT SYSTEM WITH TANK & PUMP
REMOTE PULSE GENERATOR, INTERNAL MULTI-TAP TRANSFORMER
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
