Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 20.6" x 43.3"
MAXIMUM TABLE LOAD 1,320 LBS
SPINDLE NOSE TO TABLE TOP 6.9" - 25"
X AXIS TRAVEL 32.9"
Y AXIS TRAVEL 18.7"
Z AXIS TRAVEL 18.1"
RAPID TRAVERSE RATE X AXIS 945 IPM
RAPID TRAVERSE RATE Y AXIS 945 IPM
RAPID TRAVERSE RATE Z AXIS 630 IPM
CUTTING FEED RATE 0.1 - 590 IPM
SPINDLE SPEEDS 60 - 6,000 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR (2 SPEED GEARED) 20 HP AC
TOOL CHANGER CAPACITY 30 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 1.7 SECONDS
EQUIPPED WITH:
FANUC OMC CNC CONTROL WITH 9" CRT & 80M MEMORY
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
SPINDLE OIL COOLING SYSTEM (SPINDLE CHILLER)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
