Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 14" X 30.9"
MAXIMUM TABLE LOAD 529 LBS
SPINDLE NOSE TO TABLE TOP 6.3" - 24.4"
X AXIS TRAVEL 20"
Y AXIS TRAVEL 14.1"
Z AXIS TRAVEL 18.1"
RAPID TRAVERSE RATE X AXIS 1969 IPM
RAPID TRAVERSE RATE Y AXIS 1969 IPM
RAPID TRAVERSE RATE Z AXIS 1417 IPM
CUTTING FEED RATE 0.01 - 1969 IPM
SPINDLE SPEEDS 20 - 10,000 RPM
SPINDLE TAPER BT 40
SPINDLE MOTOR (2 SPEED GEARED) 15 HP AC
TOOL CHANGER CAPACITY 24 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 1.0 SECONDS
TOOL CHANGE TIME (CHIP TO CHIP) 3.0 SECONDS
EQUIPPED WITH:
FANUC 16iM CNC CONTROL WITH 10.4" LCD
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
1280 METERS EXTENDED PROGRAM STORAGE MEMORY
SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED SPLASH GUARDING, ALL AVAILABLE MANUALS
*****PREPPED FOR COOLANT THROUGH THE SPINDLE*****
