Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 14" X 30.9"
MAXIMUM TABLE LOAD 529 LBS
SPINDLE NOSE TO TABLE TOP 5" - 20.94"
X AXIS TRAVEL 19"
Y AXIS TRAVEL 13"
Z AXIS TRAVEL 16"
B AXIS INDEXING 0.001 DEG.
RAPID TRAVERSE RATE X AXIS 787 IPM
RAPID TRAVERSE RATE Y AXIS 787 IPM
RAPID TRAVERSE RATE Z AXIS 472 IPM
SPINDLE SPEEDS 300 - 13,000 RPM
SPINDLE TAPER BT 35
SPINDLE MOTOR 7.5 HP AC
TOOL CHANGER CAPACITY 20 STATION ATC
EQUIPPED WITH:
FANUC 0M CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
8" TSUDAKOMA FULL 4TH AXIS ROTARY TABLE
SPINDLE OIL COOLING SYSTEM (SPINDLE CHILLER)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
ALL AVAILABLE BT-35 TAPER TOOL HOLDERS
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
