Specifications
Equipped With
GENERAL SPECIFICATIONS:
PALLET SIZE 15.75" X 15.75"
PALLET CHANGE TIME 5 SECONDS
MAXIMUM TABLE LOAD 880 LBS
SPINDLE NOSE TO PALLET CENTER 5.9" - 27.1"
SPINDLE CENTER TO PALLET SURFACE 2.0" - 26.0"
X AXIS TRAVEL 26"
Y AXIS TRAVEL 24"
Z AXIS TRAVEL 22"
B AXIS INDEXING 0.001 DEG.
RAPID TRAVERSE RATE X, Y & Z AXES 1969 IPM
RAPID TRAVERSE RATE B AXIS 33.3 RPM
CUTTING FEED RATE 0.1 - 1969 IPM
SPINDLE SPEEDS 35 - 13,000 RPM
SPINDLE TAPER BT 40
SPINDLE MOTOR 25 HP AC
TOOL CHANGER CAPACITY 50 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 1.3 SECONDS
EQUIPPED WITH:
FANUC 16iM CNC CONTROL WITH 10.4" LCD CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS / SOLID TAPPING)
COOLANT THROUGH THE SPINDLE (220 PSI)
1280 METERS MEMORY, STANDARD & WASH COOLANT SYSTEMS
EXTERNAL LIFT-UP TYPE CHIP CONVEYOR, FULLY ENCLOSED GUARDING
ALL AVAILABLE TOMBSTONES & TOOLING, ALL AVAILABLE MANUALS
