Specifications
Equipped With
GENERAL SPECIFICATIONS:
PALLET SIZE 13.98" x 22.05"
PALLET CHANGE TIME 5.0 SECONDS
MAXIMUM TABLE LOAD 220 LBS
SPINDLE NOSE TO TABLE TOP 6.3" - 24.4"
X AXIS TRAVEL 20.1"
Y AXIS TRAVEL 14"
Z AXIS TRAVEL 18.1"
RAPID TRAVERSE RATE X AXIS 1969 IPM
RAPID TRAVERSE RATE Y AXIS 1969 IPM
RAPID TRAVERSE RATE Z AXIS 1417 IPM
CUTTING FEED RATE 0.01 - 1969 IPM
SPINDLE SPEEDS 100 - 15,000 RPM
SPINDLE TAPER BT 40
SPINDLE MOTOR (2 SPEED GEARED) 15 HP AC
TOOL CHANGER CAPACITY 24 STATION ATC
TOOL CHANGE TIME (TOOL TO TOOL) 1.0 SECONDS
TOOL CHANGE TIME (CHIP TO CHIP) 3.0 SECONDS
EQUIPPED WITH:
FANUC 16iM CNC CONTROL WITH 10.4" LCD & RS-232C PORT
RIGID TAPPING (SYNCHRONOUS TAPPING / SOLID TAPPING)
PREPPED /PLUMBED FOR COOLANT THROUGH THE SPINDLE
OPTIONAL 15,000 RPM SPINDLE SPEED UPGRADE
1280 METERS MEMORY, BUILT-IN 8MB DATA SERVER
SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM)
LIFT-UP TYPE EXTERNAL DISCHARGE CHIP CONVEYOR
FULLY ENCLOSED SPLASH GUARDING, ALL AVAILABLE MANUALS
*****1246 POWER ON & 396 CUT HOURS*****
