Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 73.4" x 34.3"
MAXIMUM TABLE LOAD 4,000 LBS
SPINDLE NOSE TO TABLE TOP 7.8" - 31.4"
X AXIS TRAVEL 52"
Y AXIS TRAVEL 30"
Z AXIS TRAVEL 23.6"
RAPID TRAVERSE RATE X AXIS 472.4 IPM
RAPID TRAVERSE RATE Y AXIS 472.4 IPM
RAPID TRAVERSE RATE Z AXIS 472.4 IPM
CUTTING FEED RATE 0.01 - 157.4 IPM
SPINDLE SPEEDS 10 - 4,000 RPM
SPINDLE TAPER CAT 50
SPINDLE MOTOR (2 SPEED GEARED) 20 HP AC
TOOL CHANGER CAPACITY 20 STATION ATC
MAXIMUM TOOL LENGTH 15.74"
MAXIMUM TOOL WEIGHT 33 LBS
MAXIMUM TOOL LENGTH 12"
EQUIPPED WITH:
HURCO ULTIMAX II CONVERSATIONAL CNC CONTROL
DUAL/SPLIT SCREEN WITH (2) 9" CRT'S
RS-232C PORT INTERFACE FOR DNC OPERATION
DUAL DISK DRIVE, 3D EPROM SOFTWARE, COMM. UTILITY
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
*****4300 CUT HOURS TOTOL USE, ALUMINUM ONLY*****
