Specifications
Equipped With
GENERAL SPECIFICATIONS:
MANUFACTURER......................... HITACHI SEIKI
MODEL................................ HI-TECH TURN HT23SII
AGE APPROXIMATELY.................... 1996
SWING OVER BED....................... 18.1"
MAX TURNING DIAMETER................. 14."
MAX MACHINING LENGTH................. 23.6"
BAR CAPACITY......................... 2.6"
SPINDLE.............................. 3"
SPINDLE NOSE......................... A2-8
TRAVELS (X).......................... 8.2"
(Z).......................... 24.8"
SPINDLE SPEED........................ 20-3600 RPM
TURRET TOOL POSITIONS................ 10
RAPIDS (X)........................... 984 IPM
(Z)........................... 1181 IPM
MOTOR................................ 20 HP
WEIGHT APPROX........................ 12,000 LBS.
DIMENSIONS APPROX.................... 139" X 82" 80"H
EQUIPPED WITH:
TOOL EYE
MISC TOOLING
SEICOS MULTI CONTROL
CHIP CONVEYOR
MANUALS
