Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 15.0"
MAXIMUM TURNING LENGTH 15.0"
X AXIS TRAVEL 7.9"
Z AXIS TRAVEL 15.7"
RAPID TRAVERSE RATE X AXIS 787 IPM
RAPID TRAVERSE RATE Z AXIS 945 IPM
SPINDLE NOSE A2-6
SPINDLE BORE 2.4"
MAXIMUM BAR CAPACITY (ROUND) 2.0"
SPINDLE SPEEDS 30 - 5,000 RPM
SPINDLE MOTOR 15 HP AC
TURRET CAPACITY 1O STATION KV40 TURRET
EQUIPPED WITH:
GE FANUC 0TC CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
8" HOWA 3-JAW HYDRAULIC CHUCK WITH JAWS
Q-SETTER (TOOL PRESETTER), KV TOOLING (VDI)
BACK MOUNTED DRILLING SPINDLE (NO TAILSTOCK)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
FULLY ENCLOSED SPLASH GUARDING
RIGHT HAND DISCHARGE CHIP CONVEYOR
ALL AVAILABLE TOOL BLOCK HOLDERS & MANUALS
MACHINE WEIGHT 9200 LBS, RUNNING 240VOLTS
