Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 17.7"
MAXIMUM TURNING DIAMETER 13.3"
MAXIMUM TURNING LENGTH (SHAFT WORK) 15.7"
X AXIS TRAVEL 8.5"
Z AXIS TRAVEL 15.7"
RAPID TRAVERSE RATE X AXIS 1181 IPM
RAPID TRAVERSE RATE Z AXIS 1181 IPM
SPINDLE NOSE A2-6
SPINDLE BORE 2.44"
MAXIMUM BAR CAPACITY (ROUND) 2.0"
SPINDLE SPEEDS 30 - 5,000 RPM
SPINDLE MOTOR 20 HP AC
TURRET CAPACITY 10 STATION TURRET
TAILSTOCK BODY TRAVEL 11.8"
TAILSTOCK QUILL TAPER MT #5
EQUIPPED WITH:
SEICOS LY (YASNAC) CNC CONTROL W/9" LCD & RS-232C PORT
COLLET CHUCK SYSTEM, INTERFACED FOR LNS MAGAZINE BARFEED
LNS QUICKLOAD MAGAZINE BARFEED SYSTEM (5' BAR LENGTH)
Q SETTER (TOOL PRESETTER), HYDRAULIC TAILSTOCK, KV TOOLING
STANDARD COOLANT SYSTEM WITH TANK & PUMP
MAYFRAN RIGHT HAND DISCHARGE CHIP CONVEYOR
ALL AVAILABLE TOOLING, ALL AVAILABLE MANUALS
