Specifications
Equipped With
GENERAL SPECIFICATIONS:
PALLET SIZE 19.68" x 19.68"
MAXIMUM TABLE LOAD 1,980 LBS
SPINDLE NOSE TO PALLET CENTER 0" - 23.25"
SPINDLE CENTER TO PALLET SURFACE 7.87" - 31.49"
X AXIS TRAVEL 27.55"
Y AXIS TRAVEL 23.62"
Z AXIS TRAVEL 23.62"
B AXIS INDEXING 1 DEG.
RAPID TRAVERSE RATE X AXIS 400 IPM
RAPID TRAVERSE RATE y AXIS 400 IPM
RAPID TRAVERSE RATE z AXIS 400 IPM
CUTTING FEED RATE 0.1 - 157.5 IPM
SPINDLE SPEEDS 28 - 3,150 RPM
SPINDLE TAPER CAT 50
SPINDLE MOTOR 15 HP
TOOL CHANGER CAPACITY 40 STATION ATC
EQUIPPED WITH:
FANUC 11MF CNC CONTROL WITH 14" COLOR CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
DAIKIN SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM)
STANDARD COOLANT SYSTEM WITH TANK & PUMP
INTERNAL SPIRAL CHIP REMOVAL CONVEYOR
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
