Specifications
Equipped With
GENERAL SPECIFICATIONS:
CHUCK SIZE 6" x 18"
STANDARD GRINDING WHEEL SIZE 7" x 0.5" X 1.25"
MAXIMUM GRINDING WHEEL SIZE 8" x 1.25" x 1.25"
LONGITUDINAL TRAVEL 20"
CROSS TRAVEL 6.75"
VERTICAL TRAVEL 12"
VERTICAL WORKING HEIGHT 11.75"
RAPID TRAVERSE RATE Y & Z AXES 100 IPM
LONGITUDINAL SPEEDS 3 - 70 FPM
SPINDLE SPEEDS 3,450 RPM
SPINDLE MOTOR 1.5 HP
MACHINE WEIGHT 1,785 LBS
FLOOR SPACE 70" x 65"
EQUIPPED WITH:
BRIDGEPORT 32-BIT PC-BASED (DOS O/S) CONTROL W/9" CRT
RS-232 PORT INTERFACE FOR DNC OPERATION
6" x 18" WALKER ELECTRIC MAGNETIC CHUCK WITH CLAMPS & BOLTS
WET GRINDING ATTACHMENT WITH PUMP, TANK & SPLASH GUARDS
RECTIFIER, AUTOMATIC RELEASE, VAR. HOLDING & RESIDUAL RELEASE
2 AXIS (Y & Z AXES) DIGITAL READOUT SCREEN, 540 MB HARD DRIVE
38 KEY KEYBOARD, 2 AXIS LINEAR & CIRCULAR INTERPOLATION
CONVERSATIONAL DISPLAY WITH POP-UP WINDOWS & FUNCTION MENUS
ABSOLUTE / INCREMENTAL PROGRAMMING, ALL AVAILABLE MANUALS
