Specifications
Equipped With
GENERAL SPECIFICATIONS:
SWING OVER BED 22.0"
MAXIMUM TURNING DIAMETER 10.5"
MAXIMUM TURNING LENGTH 31"
DISTANCE BETWEEN CENTERS 33"
X AXIS TRAVEL 9.57"
Z AXIS TRAVEL 31.0"
RAPID TRAVERSE RATE X AXIS 472 IPM
RAPID TRAVERSE RATE Z AXIS 787 IPM
SPINDLE NOSE A2-8
ROUND 16C COLLET THROUGH CAPACITY 2.559"
SPINDLE SPEEDS 35 - 4,500 RPM
SPINDLE MOTOR 29.5 HP AC
TURRET CAPACITY 12 STATION TURRET
TURRET INDEX TIME (1 TOOL) 0.5 SECOND
TAILSTOCK QUILL TAPER MT #4
TAILSTOCK QUILL TRAVEL 6.0"
TAILSTOCK BODY TRAVEL 33.0"
EQUIPPED WITH:
FANUC 21T 32-BIT CNC CONTROL WITH 9" CRT
RS-232C PORT INTERFACE FOR DNC OPERATION
10" 3-JAW HARDINGE HYRDRAULIC THROUGH HOLE CHUCK
25C COLLET CHUCK SYSTEM, PARTS CATCHER
INTERFACED FOR MAGAZINE BARFEEDER SYSTEM
STANDARD COOLANT SYSTEM WITH TANK & PUMP
RIGHT HAND DISHCARGE LIFT-UP TYPE CHIP CONVEYOR
ALL AVAILABLE COLLETS FOR 25C COLLET SYSTEM
ALL AVAILABLE TOOL HOLDERS, ALL AVAILABLE MANUALS
