Specifications
Equipped With
GENERAL SPECIFICATIONS:
TABLE SIZE 64" x 28"
MAXIMUM TABLE LOAD 4,000 LBS
SPINDLE NOSE TO TABLE TOP 4" - 34"
X AXIS TRAVEL 64"
Y AXIS TRAVEL 32"
Z AXIS TRAVEL 30"
RAPID TRAVERSE RATE X AXIS 710 IPM
RAPID TRAVERSE RATE Y AXIS 710 IPM
RAPID TRAVERSE RATE Z AXIS 710 IPM
CUTTING FEED RATE 0.1 - 500 IPM
SPINDLE SPEEDS 0 - 7,500 RPM
SPINDLE TAPER CAT 40
SPINDLE MOTOR (VECTOR DRIVE) 20 HP AC
TOOL CHANGER CAPACITY 20 STATION ATC
MAXIMUM TOOL WEIGHT 12 LBS
EQUIPPED WITH:
HAAS 32-BIT CNC CONTROL WITH 12" CRT, CUSTOM MACROS
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING, PRE-WIRED FOR 4TH AXIS, ALL AC SERVOS
PROGRAMMABLE COOLANT NOZZLE, QUIKCODE PROGRAMMING
COORDINATE ROTATION & SCALING, FLOPPY DISK DRIVE
REMOTE PULSE GENERATOR, 1MB MEMORY UPGRADE
COIL TYPE CHIP CONVEYOR, COOLANT TANK & PUMP
FULLY ENCLOSED GUARDING, ALL AVAILABLE MANUALS
*****4080 POWER ONE & 1512 CUT HOURS PER METER*****
